主要用途
適用于中藥材的蒸、煮、燉、焯等加工.也可用于中藥的提取和濃縮以及食品、化工行業的釀造、消毒加工。
Main uses
Suitable to steam, boil and stew herb material, and it also can be used to extract, condense and disinfect in foods andchemical industries.
主要特點
易安裝、可傾斜、不污染產品、以蒸汽為熱源、鍋內及央層可分別進蒸汽、生產效率高，符合GMP要求。
Main technical characteristics
The machine is easy to install and tilt and will not cause any pollution to the herb materials. The gas goes through the pot and the mezzanine, thus it is high efficient.
主要技術參數 Main technical parameter
型號
Type |
全容積
total
volume
(m³) |
工作壓力
working
pressure
(MPa) |
工作溫度
working
temperature
(℃) |
外形尺寸
dimension
(mm) |
整機重量
weight
(kg) |
|
GZZ1000 |
1 |
<0.25 |
<139 |
2260x1210x1520 |
650 |
|
GZZ500 |
0.5 |
<0.3 |
<143 |
2230x1206x1020 |
430 |
|
GZZ300 |
0.3 |
<0.3 |
<143 |
1950x1006x1010 |
260 |
